Weiss MAN301R-S

Weiss MAN301R-S

$327,781.00 TWD
$469,663.00 TWD $327,781.00 TWD
Sale Sold out
Taxes included.
Color: Black
THE ROON MODE

The main operating mode which needs the user to have a Roon subscription in order to be able to use the Roon user interface. Roon allows to:
– stream music from Qobuz, Tidal, KKBOX, Dropbox (with the appropriate subscriptions)
– play files from local storage devices
– stream radio stations via the Internet
For more information see https://roon.app

Connect the MAN301R to your network to access your NAS devices and the Internet. Then use the Roon app to control and organize your entire music library. All common audio file formats are supported.

The MAN301R runs the Roon Core software, thus no additional computer is required.

THE PRE-AMP MODE

This mode allows the use of the MAN301R as a D/A Converter. Provided the MAN301R has a D/A Converter module installed. If there isn’t any D/A Converter installed the preamp mode can be used as a volume control for digital signals via the web interface.

The inputs available in pre-amp mode are: AES/EBU and S/PDIF on XLR, RCA and TOSLINK connectors, UPnP and airplay.

THE CD RIPPING MODE

This mode allows to rip CDs to a USB storage device plugged into the back of the MAN301R. The ripped files then can be played from within the USB storage device or can be copied to another storage device.

THE CD PLAYBACK MODE

This mode enables CD playback without ripping, providing instant access to a tracklist along with metadata.

Further controls include skip forward/backward, stop, play, and a progress bar that allows seeking within the currently playing track.

Digital Inputs:

  • (1) Ethernet connector
  • (1) XLR connector
  • (1) RCA connector
  • (1) TOSLINK connector (optical)
  • XLR, RCA, TOSLINK inputs accept professional or consumer standard, i.e. accept AES/EBU or S/PDIF signals
  • Sampling frequencies: 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz, 176.4 kHz or 192 kHz on any of the inputs, except TOSLINK input: 96 kHz maximum
  • Maximum input word-length: 24 Bits

Digital Outputs:

  • (1) XLR connector w/ AES/EBU format
  • (1) RCA connector w/ AES/EBU format
  • (1) USB type A connector
  • (1) Ethernet connector

Analogue Outputs (DAC module installed)

  • (2) XLR connectors (hot on pin 2), DC coupled, short circuit proof output circuitry, output impedance 44 Ω
  • (2) RCA connectors, DC coupled, short circuit proof output circuitry, output impedance 22 Ω
  • The output level is selectable via the web interface

Dimensions:

  • Depth: 30 cm / 11.8 inches
  • Width: 45 cm / 17.7 inches
  • Height: 6.6 cm / 2.6 inches
  • Height with feet: 7.4 cm / 2.9 inches
